Crown Series

Only one safe can be the best. Champion’s Crown Series has won its title for being the crowning achievement in safe manufacturing. The Crown is the perfect synthesis of strength, fire protection, precision, and elegance. The Crown’s thick 3/16-inch body with the Steel Arch Doorway™ and massive Delta Force™ door work together with sophisticated door defense systems to create the ultimate standard in security. The precision radial gear–driven boltworks possess unsurpassed strength and smoothness. The Crown’s 1750°F two-hour fire rating is one of the best in the industry. The plush velour interior features LED lighting and a custom door organizer for convenience. Four two-tone and five high-gloss mirror finishes add a final touch of class. Only one safe can be the best—it’s the Crown.

  • Fire and Security Ratings

    • 1750°F Two-Hour Fire Rating
    • Phoenix™ Class V Fire Protection
    • Tested in an ASME Certi?ed Facility
    • UL® Security Rating
    • Lifetime Warranty

    Locking System

    • Sargent & Greenleaf® Group II Dial Lock
    • Glass-Guard™ Relock System with Remote Relockers
    • Champion’s Auto-Relock™ System
    • Diamond-Embedded Armor Plate™

    Boltworks

    • Radial Gear–Driven Boltworks
    • Four-Way Active Boltworks
    • Up to 22, 1-1/2″- Diameter Door Bolts
    • Bolt-Detent™ System
    • Roughneck™ Bolt Guides
  • Interior

    • Plush Velour Interior
    • Dual Floor Drawers
    • Bank Box™ Storage System (CR-65, CR-55)
    • LED Lighting with Motion Sensor
    • 110-Volt Power Receptacle
    • Deluxe Door Organizer

    See Interior Configurations Below

    Maximum Security Door

    • Exclusive Five-Inch Thick Delta Force™ Door
    • 3/4″ Reinforced Door Edge
    • 3/8″ Outer Door Steel, Full 10-Gauge Inner
    • Three Layers of Fire Insulation
    • Internal Ball-Bearing Hinges
    • Five-Spoke Custom Handle with Slip Clutch

    Body

    • Classic Steel Arch Doorway™
    • Up to 2-1/4″-Thick Composite Walls
    • 3/16″ Steel Walls
    • Four Layers of Fire Insulation
    • Double-Steel Door Casement™
    • Dual Fire Seals





Locks


Standard Dial                                       Optional E-Lock



Exterior/Interior Color Selections



Sizes and Dimensions

Safe ModelExterior DimensionsVolume (Cubic Ft.)Approx. Weight (lbs.)Outer Shell ThicknessOuter Door ThicknessInner Door ThicknessActive Door BoltsGun Capacity
WidthHeightDepthTotal Depth*
CR-6552-1/2"73"27-1/2"30"61 CF19753/16"3/8"10 ga.22 - 1-1/2"64/58**
CR-5545-1/2"73"27-1/2"30"53 CF18003/16"3/8"10 ga.20 - 1-1/2"58/49**
CR-4539-1/2"67"27-1/2"30"42 CF15253/16"3/8"10 ga.16 - 1-1/2"49
CR-3533-1/2"67"25-1/2"28"33 CF12753/16"3/8"10 ga.16 - 1-1/2"36
*Total Depth includes 2½" for handle. **With Bank Box™ Storage Drawers



Interior Layouts

champion-interior-safe-layouts
