Medalist Series

The Medalist Series is our most popular safe—and for good reason. It offers excellent security, ?re protection, and quality at an attractive price. The Medalist’s body is formed from 12-gauge American-made steel with a reinforced Double-Steel Door Casement™. Its Double Plate Steel Door™ is constructed from two full layers of steel and encases a precision four-way active boltworks. Other features include: clutch-driven mechanism, complete door defense systems, and Champion’s bolt-detent. Its 1400°F 60-minute ?re rating is unmatched in its price range. After careful examination, you’ll ?nd the Medalist Series surpasses all other safes in its class. In fact, you’ll ?nd it superior to most higher-priced products on the market.

  • Fire and Security Ratings

    • 1400° 60-Minute Fire Rating
    • Phoenix™ Class II Fire Protection
    • Tested in an ASME Certi?ed Facility
    • UL® Security Rating
    • Lifetime Warranty

    Locking System

    • Sargent & Greenleaf® Group II Dial Lock
    • Champion’s Auto-Relock™ System
    • Diamond-Embedded Armor Plate™


    • Four-Way Active Boltworks
    • Up to 14, 1-1/4″-Diameter Door Bolts
    • Bolt-Detent™ System
    • Roughneck™ Bolt Guides
  • Interior

    • Plush Velour Interior
    • High Capacity Gun Racks
    • Steel Reinforced Top Shelf
      (MD-45, MD-41)
    • Deluxe Door Organizer

    See Interior Configurations Below

    High Security Door

    • 4-1/2″-Thick Double Plate Steel Door™
    • 11-Gauge Outer Steel, Full 14-Gauge Inner
    • 1/2″ Reinforced Door Edge
    • Internal Ball-Bearing Hinges
    • Two Layers of Fire Insulation
    • Three-Spoke Handle with Slip Clutch


    • Up to Two-Inch Thick Composite Walls
    • 12-Gauge Steel Walls
    • Up to Three Layers of Fire Insulation
    • Double-Steel Door Casement™



Standard Dial                                       Optional E-Lock


Exterior Color Selections


Sizes and Dimensions

Safe ModelExterior DimensionsVolume (Cubic Ft.)Approx. Weight (lbs.)Outer Shell ThicknessOuter Door ThicknessInner Door ThicknessActive Door BoltsGun Capacity
WidthHeightDepthTotal Depth*
MD-4541"72-1/2"26"28-1/2"44 CF90012 ga.11 ga.14 ga.14 - 1-1/4"52
MD-4140"60-1/2"26"28-1/2"37 CF77512 ga.11 ga.14 ga.12 - 1-1/4"52
MD-3136"60-1/2"22"24-1/2"28 CF62512 ga.11 ga.14 ga.12 - 1-1/4"39
MD-2230"60-1/2"21"23-1/2"22 CF52512 ga.11 ga.14 ga.12 - 1-1/4"24
MD-1724"60-1/2"20"22-1/2"17 CF47512 ga.11 ga.14 ga.12 - 1-1/4"12
*Total Depth includes 2½" for handle.


Interior Layouts
