Trophy Series

Built with the same exacting precision and superiority as Champion’s higher-end models, the Trophy Series offers rugged protection. Its 11-gauge steel body, reinforced with a Double-Steel Door Casement™, provides a solid steel foundation. Its thick Double Plate Steel Door™ with full inner door steel and numerous 1¼”-diameter four-way active door bolts provide excellent security. The Trophy’s door defense system includes: Champion’s Auto-Relock™ system and Diamond-Embedded Armor Plate™. To protect from the hottest ?res, it boasts a 1500°F 75-minute ?re rating. The Trophy Series comes in high-gloss and textured finishes, with a velour-covered interior and convenient door organizer.

  • Fire and Security Ratings

    • 1500°F 75-Minute Fire Rating
    • Phoenix™ Class III Fire Protection
    • Tested in an ASME Certi?ed Facility
    • UL® Security Rating
    • Lifetime Warranty

    Locking System

    • Sargent & Greenleaf® Group II Dial Lock Standard
    • Champion’s Auto-Relock™ System
    • iamond-Embedded Armor Plate™

    Boltworks

    • Four-Way Active Boltworks
    • Up to 16, 1-1/4″-Diameter Door Bolts
    • Bolt-Detent™ System
    • Roughneck™ Bolt Guides
  • Interior

    • Plush Velour Interior
    • High Capacity Gun Racks
    • LED Lighting with Motion Sensor
    • 110-Volt Power Receptacle
    • Steel Reinforced Top Shelves
      (TY-60, TY-50, TY-42, TY-35)
    • Deluxe Door Organizer

    See Interior Configurations Below

    High Security Door

    • 4-1/2″-Thick Double Plate Steel Door™
    • 10-Gauge Outer Steel, Full 14-Gauge Inner
    • 3/4″ Reinforced Door Edge
    • Internal Ball-Bearing Hinges
    • Three Layers of Fire Insulation
    • Five-Spoke Handle with Slip Clutch

    Body

    • Up to Two-Inch Thick Composite Walls
    • 11-Gauge Steel Walls
    • Up to Three Layers of Fire Insulation
    • Double-Steel Door Casement™



Locks


Standard Dial                                       Optional E-Lock



Exterior Color Selections



Sizes and Dimensions

Safe Model Exterior Dimensions Volume (Cubic Ft.) Approx. Weight (lbs.) Outer Shell Thickness Outer Door Thickness Inner Door Thickness Active Door Bolts Gun Capacity
Width Height Depth Total Depth*
TY-60 50" 72" 28" 30-1/2" 59 CF 1275 11 ga. 10 ga. 14 ga. 16 - 1-1/4" 62
TY-50 42" 72" 28" 30-1/2" 51 CF 1105 11 ga. 10 ga. 14 ga. 16 - 1-1/4" 52
TY-40 36" 66" 26" 28-1/2" 42 CF 905 11 ga. 10 ga. 14 ga. 14 - 1-1/4" 42
TY-25 30" 60" 24" 26-1/2" 26 CF 705 11 ga. 10 ga. 14 ga. 14 - 1-1/4" 24
*Total Depth includes 2½" for handle.



Interior Layouts

champion-interior-safe-layouts
